Omada 25GBase-SR SFP28 LC Transceiver Spec: Dual Rate 25.78 Gbps and 10…

Popis produktu

SM6110-SR Vysielač Omada 25GBase-SR SFP28 LC Multimódový transceiver SFP+/SFP28 LC Hot-pluggable s maximálnou flexibilitou Podporuje digitálny diagnostický monitoring (DDM) Nízka spotreba energie, nie viac ako 1 W Kompatibilná s 10G/25G Small Form Pluggable Multi-Source Agreement (SFP+/SFP28 MSA) Kompatibilné so switchemi s 25G porty, ako je SX6632YF; 10G port, ako sú SG3428X a SG3452X. PACKAGE CONTENTS Package Contents • SM6110-SR • Installation Guide HARDWARE FEATURES DDM Yes SFP-MSA Yes Hot Swappable Yes Dimensions ( W x D x H ) 2.24*0.55*0.53 in (57*14*13.45 mm) Transceiver Standards and Protocols • IEEE 802.3ae, 802.3by • SFF-8402, SFF-8431, SFF-8432, SFF-8472 • eCPRI, CPRI • TCP/IP Wavelength 850nm Power Supply 3.3V Fiber Type 50/125um or 62.5/125um Multi-mode Max. Cable Length 70m (OM3) @25.78Gbps, 100m (OM4) @25.78Gbps, 300m (OM3) @10.31Gbps Support Data Rate Dual Rate 25.78 Gbps and 10.31 Gbps Connector Duplex LC/UPC Regulatory Compliance CE, FCC, RoHS Environment • Operating Temperature: 0°C to 70°C (32–158 ?) • Storage Temperature: -40°C to 85°C (-40°F to 185°F) • Operating Humidity: 10% to 90% RH non-condensing • Storage Humidity: 5% to 90% RH non-condensing
